Auditorium Chair
Auditorium Chairs CF 04
Get Best Quote
Push-back cushioned auditorium chair with optional writing pad.
- Key Features
- Ergonomic comfort: Contoured backrest with lumbar support.
- Premium cushioning: High-density polyurethane foam with a specified density of 40 ± 3.
- Durable upholstery: 100% synthetic fabric.
- Strong armrests: Integral teak wood or reinforced PP with M.S. inserts.
- Tip-up mechanism: M.S. fabricated linkage system with coordinated seat and back movement.
- Robust construction: M.S. fabricated frame with 2 mm thick CR steel side-panel frames.
- Reinforced assemblies: Marine plywood, ABS components, and upholstered MDF side panels.
- Secure installation: Floor-mounted side panels fixed using foundation expansion bolts.
- Space-efficient design: Integrated movement mechanism suitable for auditorium seating layouts.
- ✔ Delivery across Bihar
- ✔ Custom size available
- ✔ Bulk order pricing
Product Description
Premium Auditorium Chair (CF-04) – Product Description
The premium auditorium chair is designed to deliver superior seating comfort, durability, and an elegant appearance for auditoriums, conference halls, educational institutions, training centres, and multipurpose halls. Its ergonomic backrest features contoured lumbar support, while the high-density polyurethane foam cushioning and upholstered synthetic fabric provide a comfortable seating experience for extended periods.
The chair is constructed with a robust mild-steel (M.S.) fabricated frame and floor-mounted side-panel supports for enhanced stability. The armrests are made of integral teak wood or reinforced polypropylene (PP) with an M.S. insert, offering strength and a refined finish. The integrated tip-up mechanism enables coordinated seat and back movement, with a 100 mm seat sliding stroke, helping facilitate convenient movement and space management.
The upholstered MDF side panels, plywood-reinforced seat and back assemblies, and securely anchored pedestal supports contribute to the chair's structural strength and long-term performance. Its carefully specified dimensions support comfortable seating and practical installation in institutional and commercial environments.
Technical Specifications
Parameter | Specification |
|---|---|
Overall width, outer arm to arm | 650 mm |
Centre-to-centre arm spacing | 600 mm |
Seat width | 465 mm |
Seat depth | 500 mm |
Floor-to-seat height | 440 mm |
Backrest width | 465 mm |
Backrest height above seat | 675 mm |
Overall height (drawing reference) | 1,020 mm |
Armrest height from floor | 600 mm |
Armrest width | 85 mm |
Side-panel frame | 2 mm thick CR steel |
M.S. leg/pedestal | 80 × 30 × 2 mm oval pipe |
Seat sliding stroke | 100 mm |
Upholstery | 100% synthetic fabric |
Cushioning | High-density polyurethane foam, 40 ± 3 density |
Recommended Applications
Auditoriums and lecture halls
Universities, colleges, and schools
Conference and seminar halls
Corporate training centres
Government and institutional buildings
Multipurpose halls and assembly spaces
Product positioning: A durable, ergonomically designed auditorium seating solution combining comfortable cushioning, robust steel construction, and a space-efficient movement mechanism for professional institutional environments.
Technical note: The supplied specifications mention both 1.5 cm marine plywood for the seat-rest assembly and ABS components reinforced with plywood for the seat and back assemblies. Confirm the exact construction details against the approved manufacturing drawing before using this description in a formal tender or technical submission.
